High Performance 0Cr15Al5 Alloy Wire for Hydrogen Generation

ブランド名:	DLX
モデル番号:	FeCrAl合金ワイヤー0Cr15Al5
Moq:	10kg
支払条件:	L/C、D/A、D/P、T/T、ウェスタンユニオン
供給能力:	月産500トン

詳細情報

製品の説明

詳細情報

起源の場所:

中国、江蘇省

証明:

Ce,Rohs

供給の能力:

月産500トン

ハイライト:

0Cr15Al5 alloy resistance wire

hydrogen generation resistance wire

high performance alloy wire

製品の説明

High Performance 0Cr15Al5 Alloy Wire for Hydrogen Generation

In the evolving landscape of green energy, hydrogen generation plays a pivotal role in enabling sustainable energy solutions. To meet the growing demand for efficient hydrogen production, electrolysis systems require durable, high-performance materials capable of withstanding the harsh conditions inside electrolyzers. The 0Cr15Al5 FeCrAl Alloy Wire is an advanced solution, specifically engineered for superior performance in hydrogen generation applications, particularly in water electrolysis.

Composed of a high-quality FeCrAl alloy, the 0Cr15Al5 Alloy Wire excels in offering enhanced corrosion resistance, thermal stability, and mechanical strength, ensuring long-term reliability and high efficiency in electrolysis systems. Whether used in alkaline or high-temperature electrolysis systems, this alloy wire plays a critical role in maximizing the output of green hydrogen, helping to accelerate the global transition to sustainable energy sources.

Parameter Comparison Table

Alloy Nomenclature Performance	1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Chemical Composition (%) - Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
Chemical Composition (%) - Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
Chemical Composition (%) - Re	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune
Chemical Composition (%) - Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
Max. Continuous Service Temp. of Element (°C)	950	1250	1250	1250	1100	1350	1400
Resistivity at 20°C (μΩ.m)	1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density (g/cm³)	7.4	7.1	7.16	7.25	7.35	7.1	7.1
Thermal Conductivity (KJ/m.h)	52.7	46.1	63.2	60.2	46.9	46.1	--
Coefficient of Linear Expansion (α×10⁻⁶/°C)	15.4	16	14.7	15	13.5	16	16
Melting Point Approx (°C)	1450	1500	1500	1500	1500	1510	1520
Tensile Strength (N/mm²)	580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at Rupture (%)	>16	>12	>12	>12	>12	>12	>10
Reduction of Area (%)	65-75	60-75	65-75	65-75	65-75	65-75	65-75
Repeat Bending Frequency (F/R)	>5	>5	>5	>5	>5	>5	>5
Hardness (H.B.)	200-260	200-260	200-260	200-260	200-260	200-260	200-260
Continuous Service Time (Hours/°C)	--	≥80/1300	≥80/1300	≥80/1300	≥80/1250	≥80/1350	≥80/1350
Micrographic Structure	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite
Magnetic Properties	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic

Available Shapes and Sizes

Shape	Size (mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)×(0.5-6.0)
Strip	(0.5-2.5)×(5-180)

Key Features of 0Cr15Al5 Alloy Wire

Exceptional Corrosion Resistance: Demonstrates outstanding resistance to oxidation and corrosion, even in highly aggressive electrolytes, ensuring longevity and reduced maintenance costs.
High-Temperature Stability: With a melting point of 1,420°C, designed to perform reliably in high-temperature electrolysis applications for continuous operation.
Superior Mechanical Strength: Impressive tensile and yield strength withstands mechanical stresses and pressures in electrolyzers, maintaining system stability.
Low Wear and Tear: Hardness and oxidation resistance reduce wear, contributing to longer equipment lifespan and minimized downtime.
Tailored Specifications: Available in various wire sizes and customizable to meet specific requirements of different electrolysis systems.

Applications of 0Cr15Al5 Alloy Wire

Water Electrolysis for Hydrogen Production: Exceptional corrosion resistance and thermal stability make it perfect for efficient hydrogen generation in water electrolysis systems.
Alkaline Electrolysis: Resists corrosion from alkaline electrolytes, providing durable solutions for continuous hydrogen production.
High-Temperature Electrolysis: High thermal stability supports hydrogen production at elevated temperatures for enhanced system efficiency.
Fuel Cells and Energy Storage: Used in fuel cells and energy storage systems where corrosion resistance and mechanical strength improve overall performance.
Hydrogen Production R&D: Relied upon for testing and optimizing new hydrogen generation methods in research and development projects.

Industry Trends and Applications

Hydrogen is widely recognized as a clean and versatile energy carrier, with applications spanning from transportation to power generation and industrial processes. As part of the global push for decarbonization, the hydrogen economy is rapidly expanding, and electrolysis has emerged as the leading method for producing green hydrogen. This method uses electricity to split water into hydrogen and oxygen, with the potential for net-zero emissions when powered by renewable energy.

The demand for efficient and durable materials in electrolysis systems has never been higher. The 0Cr15Al5 Alloy Wire is an ideal solution, providing both high performance and long-lasting durability in demanding environments. As hydrogen generation technologies advance, the need for high-quality materials like the 0Cr15Al5 Alloy Wire will continue to grow, making it an essential component in the future of clean energy.

The growing interest in hydrogen-powered fuel cells, especially in sectors like automotive and heavy industry, further drives the need for reliable electrolysis systems. The 0Cr15Al5 Alloy Wire is well-positioned to support this trend, contributing to the development of more efficient and sustainable hydrogen production methods.

Why Choose 0Cr15Al5 Alloy Wire?

Long-Term Durability: Corrosion resistance and high thermal stability ensure longer lifespan than conventional materials, reducing replacements and maintenance costs.
Improved Hydrogen Efficiency: Reliable performance under extreme conditions maximizes hydrogen yield and system efficiency.
Customizable for Specific Systems: Available in various sizes and specifications to suit unique needs of different electrolysis setups.
Cost-Effective Solution: Long-term benefits of reduced maintenance and increased efficiency make it a cost-effective choice despite higher initial investment.
Sustainability: Enables efficient green hydrogen production, supporting the transition to sustainable, renewable energy sources and reducing carbon emissions.

Frequently Asked Questions

What is 0Cr15Al5 Alloy Wire made of?

The 0Cr15Al5 Alloy Wire is a high-performance alloy consisting of iron (Fe), chromium (Cr), and aluminum (Al), providing excellent resistance to oxidation, high temperatures, and mechanical stress.

How does the alloy wire perform in electrolysis systems?

The 0Cr15Al5 Alloy Wire resists corrosion from both alkaline and acidic electrolytes, ensuring reliable and long-lasting performance in electrolysis systems used for hydrogen production.

Can the alloy wire be used in high-temperature electrolysis systems?

Yes, the 0Cr15Al5 Alloy Wire has a high melting point of 1,420°C, making it ideal for high-temperature electrolysis applications.

How does the 0Cr15Al5 Alloy Wire enhance hydrogen production?

The wire's corrosion resistance and mechanical strength ensure stable performance over time, leading to more efficient hydrogen generation with minimal downtime.

Can this wire be customized for specific applications?

Yes, the 0Cr15Al5 Alloy Wire comes in various sizes and can be tailored to meet the unique specifications of different electrolysis systems.

Is the 0Cr15Al5 Alloy Wire suitable for both alkaline and PEM electrolysis?

Yes, it performs well in both alkaline and PEM (Proton Exchange Membrane) electrolysis systems, providing excellent resistance to corrosion in both environments.

What industries use 0Cr15Al5 Alloy Wire?

The 0Cr15Al5 Alloy Wire is used in hydrogen production, fuel cells, energy storage, and industrial electrolysis systems, as well as in research and development for advanced hydrogen generation technologies.

How does the 0Cr15Al5 Alloy Wire support green energy goals?

By enabling efficient and long-lasting hydrogen production, the 0Cr15Al5 Alloy Wire contributes to the development of clean energy solutions, supporting the global transition to a low-carbon economy.
