High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties

High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties

ブランド名: DLX
モデル番号: プラチナ・イリジウム
Moq: 15kg
支払条件: L/C、D/A、D/P、T/T、Western Union、MoneyGram
詳細情報
起源の場所:
中国
証明:
Ce,Rohs
ハイライト:

High-Precision Platinum Iridium Alloy Ring

,

Medical and Aerospace Pt-Ir Ring

,

Biocompatible Platinum Iridium Component

製品の説明
Platinum Iridium Alloy Ring | High-Precision Medical and Aerospace Component
Platinum Iridium alloy (Pt-Ir) is a high-performance noble metal material known for its excellent corrosion resistance, electrical stability, and mechanical strength. It typically contains 5% to 30% iridium, which greatly enhances the hardness and wear resistance of platinum. Common grades include Pt5Ir, Pt10Ir, Pt20Ir, and Pt30Ir. These alloys maintain outstanding mechanical and chemical stability, even under extreme environments such as high temperatures, vacuum, and acidic conditions.
At DLX, we produce platinum iridium alloy rings, tubes, and springs using precision melting and forming technology. Our alloys meet strict international standards such as ASTM B684 (U.S.), DIN 17744 (Germany), and ISO 11490 (Europe), ensuring consistent purity, density, and performance across every batch.
High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 0
Applications
Platinum Iridium alloy rings are used in high-precision and high-reliability industries:
  • Medical Industry: Used for implantable components, pacemaker contacts, and surgical instruments due to biocompatibility.
  • Aerospace: Ideal for sensors, jet engine components, and thermocouple parts because of stability at high temperatures.
  • Electronics: Applied in precision connectors, electrodes, and switches requiring consistent conductivity.
  • Laboratory Instruments: Used in crucibles, thermocouples, and analytical equipment for their resistance to oxidation and contamination.
  • Jewelry & Watches: Preferred for luxury products requiring a balance of beauty, durability, and wear resistance.

Industry Trend
Global demand for platinum group metals is increasing due to the expansion of aerospace, semiconductor, and medical device industries. The Pt-Ir alloy market is shifting toward miniaturization and higher precision. Manufacturers are focusing on tighter dimensional tolerances, improved surface finishes, and enhanced purity levels.
At the same time, the sustainability trend is driving recycling and reclaiming processes for precious metals, making suppliers with in-house refining capability--like DLX--more competitive.
DLX Advantage
DLX Alloy Company focuses on the production of high-purity platinum group metal materials. Our strengths include:
  • Customized Composition Control: We offer Pt-Ir alloys from 5% to 30% Iridium, tailored to specific mechanical and conductivity requirements.
  • Vacuum Melting & Precision Rolling: Ensures uniform grain structure, tight tolerance, and mirror-smooth finish.
  • Strict Quality Standards: Each batch is tested for chemical composition, hardness, density, and electrical resistivity.
  • Flexible Production: Small and large orders accepted, from precision rings to drawn tubes and spring wires.
  • In-House Machining & Forming: Allows us to deliver finished rings, tubes, and springs ready for assembly or final polishing.
  • Fast Delivery & Technical Support: Global logistics network ensures quick response and consistent material traceability.
Our Pt-Ir rings are widely used by high-tech manufacturers in Europe, the U.S., and Asia. Whether for aerospace thermocouple components or micro medical implants, DLX guarantees stable performance and long lifespan.

Comparison Table
Property / Grade Pt5Ir Pt10Ir Pt20Ir Pt30Ir
Iridium Content (%) 5 10 20 30
Density (g/cm³) 21.45 21.55 21.70 21.85
Hardness (HV) 100 120 160 200
Electrical Resistivity (µΩ*cm) 10.5 11.0 12.0 13.0
Melting Point (°C) 1770 1780 1790 1800
Corrosion Resistance Excellent Excellent Superior Superior
Workability Excellent Good Fair Moderate
Typical Application Jewelry, Lab Parts Electrodes, Sensors Aerospace Rings High-Temp Springs


Platinum Iridium Alloy Ring -- The Benchmark for Precision and Reliability
Platinum Iridium alloys have a long history in precision engineering. Originally developed for standard weights and measurement instruments, this material has evolved into one of the most advanced functional metals for aerospace and medical use. Its combination of strength, corrosion resistance, and conductivity makes it indispensable in fields where reliability defines success.
At DLX, we have mastered the art of Pt-Ir alloy processing. Every ring starts from high-purity platinum and iridium metals that are vacuum melted to eliminate impurities. The molten alloy is then forged and rolled under strict temperature control to achieve fine grain uniformity. After forming, each ring undergoes heat treatment, mechanical testing, and microscopic inspection to ensure it meets international aerospace and medical standards.
Our clients value DLX not just for material quality, but for engineering precision. We understand that a single component, such as a thermocouple ring or medical electrode, can determine the safety and accuracy of an entire system. Therefore, our team ensures that each piece delivers consistent electrical stability, dimensional accuracy, and long-term durability.
In the current market, where manufacturers are pushing for smaller, lighter, and more efficient components, DLX's advanced alloy refining and forming capabilities make us a reliable long-term partner. Our products combine metallurgical innovation with craftsmanship -- the result is a platinum iridium alloy ring that performs with precision and endurance, even under the most demanding conditions.
From concept to delivery, DLX provides complete technical support -- including alloy design, machining, and surface finishing. Whether you need Pt10Ir for medical electrodes or Pt20Ir for aerospace sensors, we deliver consistent quality backed by years of metallurgical expertise.
Choosing DLX means choosing a manufacturer that doesn't just supply metal -- we deliver performance, reliability, and trust.
High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 1
High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 2
High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 3
High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 4

About Us:

Our 12,000㎡ factory is equipped with complete capabilities for research, production, testing, and packaging. We strictly adhere to ISO 9001 standards in our production processes, with an annual output of 1,200 tons. This ensures that we meet both quantity and quality demands. Furthermore, all products undergo rigorous simulated environment testing including high temperature, high pressure, and corrosion tests before being dispatched, ensuring they meet customer specifications. For all our clients, we offer timely and multilingual after-sales support and technical consulting, helping you resolve any issues swiftly and efficiently.

High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 5

Client Visits

Building Stronger Partnerships

High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 6

We support all kinds of testing:

High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 7

High-Precision Platinum Iridium Alloy Ring for Medical and Aerospace Applications with Biocompatible Properties 8


1. What is the composition of Platinum Iridium alloy?
It is primarily platinum with 5%-30% iridium added to improve hardness and wear resistance.
2. Why choose Pt-Ir alloy over pure platinum?
It offers higher strength, better hardness, and longer life under mechanical stress or heat.
3. Is Platinum Iridium biocompatible?
Yes, it is completely safe for human body contact, making it ideal for implants and medical sensors.
4. What are the typical applications of Pt-Ir rings?
They are used in aerospace components, medical devices, and high-end laboratory instruments.
5. How is the Pt-Ir alloy manufactured at DLX?
We use vacuum induction melting and precision rolling to ensure purity, density, and consistency.
6. Can DLX provide custom sizes or compositions?
Yes, we can tailor composition ratios, dimensions, and mechanical properties according to your needs.
7. How does Pt-Ir perform in high temperatures?
It retains stability and mechanical strength up to around 1700°C, making it ideal for high-temperature environments.
8. Does DLX offer material certification?
Absolutely. We provide full material traceability and testing reports including chemical composition and mechanical properties.
